Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | Opal diffuser |
| Installation: | Recessed mounted |
Electrical
| Driver: | LED driver with external connection |
| Light Source: | SMD LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 36,000 hours |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Direct |
| Beam Angle: | 120° |
| UGR: | <21 |
| CRI: | >80 |
Options
| RAL Selection: | Available |
| Dimming: | DALI-1-10V-Phase dimming |
| Control: | Emergency kit – CBS connection |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (Q×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| IDS-551-003 | 3W | 290* | 2700K-6500K | 85×10 | 74 | 0,12 kg. |
| IDS-552-006 | 6W | 550* | 2700K-6500K | 120×10 | 106 | 0,17 kg. |
| IDS-553-009 | 9W | 795* | 2700K-6500K | 145×10 | 134 | 0,23 kg. |
| IDS-554-012 | 12W | 1090* | 2700K-6500K | 174×10 | 154 | 0,30 kg. |
| IDS-555-015 | 15W | 1410* | 2700K-6500K | 200×10 | 182 | 0,37 kg. |
| IDS-556-018 | 18W | 1640* | 2700K-6500K | 225×10 | 205 | 0,48 kg. |
| IDS-557-024 | 24W | 2160* | 2700K-6500K | 300×10 | 276 | 0,89 kg. |
