Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | PC LED Lenses |
| Installation: | Surface or suspended mounted |
Electrical
| Light Source: | Mid Power LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50,000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Symmetrical |
| Beam Angle: | 90° | CRI: | >80 |
Options
| RAL Selection: | Available |
| Beam Angle: | Available |
| Dimming: | DALI – 1-10V – Step dim |
| 3H: | Emergency kit |
| Installation: | Suspension Kit |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (d×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| IIS-801-060 | 60W | 9600* | 3000K-6500K | 290×150 | N/A | 2,20 kg. |
| IIS-801-070 | 70W | 11200* | 3000K-6500K | 290×150 | N/A | 2,20 kg. |
| IIS-801-100 | 100W | 16000* | 3000K-6500K | 290×150 | N/A | 2,20 kg. |
| IIS-802-120 | 120W | 19200* | 3000K-6500K | 340×150 | N/A | 3,00 kg. |
| IIS-802-200 | 200W | 32000* | 3000K-6500K | 340×150 | N/A | 3,00 kg. |
