Rama
- Açıklama
Description;
Outdoor lighting solution with endless options, from customized lengths to beam angles and downlight or up and down light features. It is designed as a one-stop product for all needs of outdoor lighting.
Features
| Mechanical |
| Body: | Aluminium |
| Finish: | Electrostatic powder painted |
| Installation: | Ground mounted |
| Optics: | PMMA lens |
| Electrical |
| Driver: | LED driver inside the body |
| Light Source: | Power LED |
| Frequency: | 220-240V 50/60 Hz |
| Lifetime: | 50.000 hours Pf>0.90 |
| Operating Temperature: | -20 / +50 |
| Options: |
| DALI |
| Length options |
| Optical: |
| Beam angle: Asymmetrical |
| Number of heads to be selectedas per project |
| CRI>80 |
| McAdams Step<3 |
| Technical Chart |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Dimensions (H) (mm.) | Pole Length(mm.) |
| EUS-926-030-830 | 30W | 3000 | 3200 | 230×380 | 4000 – 7000 |
| EUS-926-030-840 | 30W | 4000 | 3450 | 230×380 | 4000 – 7000 |
| EUS-926-030-850 | 30W | 6500 | 3620 | 230×380 | 4000 – 7000 |
| Technical Chart |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Dimensions (H) (mm.) | Pole Length(mm.) |
| EUS-926-060-830 | 60W | 3000 | 6300 | 230×380 | 4000 – 7000 |
| EUS-926-060-840 | 60W | 4000 | 6500 | 230×380 | 4000 – 7000 |
| EUS-926-060-850 | 60W | 6500 | 6740 | 230×380 | 4000 – 7000 |
