Technical Drawing
Mechanical
| Body: | Extruded aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | Opal diffuser |
| Installation: | Surface mounted |
Electrical
| Driver: | LED driver inside the body |
| Light Source: | SMD LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50,000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Direct |
| Beam Angle: | 120° |
| UGR: | <21 |
| CRI: | >80 |
| McAdams Step: | <3 |
Options
| RAL Selection: | Available |
| CRI Option: | CRI > 90 |
| Dimming: | DALI-1-10V-Phase dimming |
| Control: | Casambi – Bluetooth control- 3H Kit -CBS Connection |
| IP Selection: | IP54 protection |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (W×L×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| ITS-920-006 | 6W | 700* | 2700K-6500K | 61x311x35 | N/A | 0,35 kg. |
| ITS-920-010 | 10W | 1200* | 2700K-6500K | 61x630x35 | N/A | 0,56 kg. |
