Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | PC Lenses |
| Installation: | Wall surface mounted |
Electrical
| Light Source: | COB LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Up&Down or Single Direction |
| CRI: | >80 |
| Beam Angle: | 15-30-45-60 degrees |
| McAdams Step: | <3 |
Options
| RAL selection: | Available |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (Q×H) mm | Light Direction | Weight (kg) |
|---|---|---|---|---|---|---|
| EFS-033-020 | 2×10W | 2200* | 3000K–6500K | 150×200 | Up&Down | 1,20 kg |
