Atlas-S
- Açıklama
Description;
Surface mounted downlight with aluminium body and frame to provide optimal heat transfer. Opal plexiglass diffuser with wide beam provides high efficiency and homogeneous light output. Various sizes in same family helps to build the design and architecture.
Technical Drawing
Features
| Mechanical |
| Body: | Aluminium |
| Finish: | Electrostatic powder painted |
| Installation: | Ceiling surface mounted |
| Diffuser: | Opal plexiglass diffuser |
| Electrical |
| Driver: | LED driver inside the body |
| Light Source: | SMD LED |
| Frequency: | 220-240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Operating Temperature: | -20 / +50 |
| Options: |
| RAL selection |
| CRI>90 |
| Microprismatic diffuser – UGR<19 |
| DALI |
| 0-10V / 1-10V |
| Casambi |
| Emergency kit / CBS connection |
| Optical: |
| Beam angle: 120 degrees |
| UGR:< 21 |
| CRI>80 |
| McAdams Step<3 |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-507-008-830 | 8W | 810 | 3000K | 108×100 | 1,0 kg. |
| IDS-507-008-840 | 8W | 840 | 4000K | 108×100 | 1,0 kg. |
| IDS-507-008-865 | 8W | 900 | 6500K | 108×100 | 1,0 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-508-012-830 | 12W | 1150 | 3000K | 128×100 | 1,4 kg. |
| IDS-508-012-840 | 12W | 1200 | 4000K | 128×100 | 1,4 kg. |
| IDS-508-012-865 | 12W | 1280 | 6500K | 128×100 | 1,4 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-509-015-830 | 15W | 1500 | 3000K | 150×100 | 1,6 kg. |
| IDS-509-015-840 | 15W | 1620 | 4000K | 150×100 | 1,6 kg. |
| IDS-509-015-865 | 15W | 1690 | 6500K | 150×100 | 1,6 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-510-020-830 | 20W | 2070 | 3000K | 180×100 |
1,8 kg. |
| IDS-510-020-840 | 20W | 2200 | 4000K | 180×100 | 1,8 kg. |
| IDS-510-020-865 | 20W | 2280 | 6500K | 180×100 | 1,8 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-511-025-830 | 25W | 2500 | 3000K | 200×100 | 2,0 kg. |
| IDS-511-025-840 | 25W | 2550 | 4000K | 200×100 | 2,0 kg. |
| IDS-511-025-865 | 25W | 2600 | 6500K | 200×100 | 2,0 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (QxH)(mm) | Weight (kg.) |
| IDS-512-030-830 | 30W | 3060 | 3000K | 240×100 | 2,4 kg. |
| IDS-512-030-840 | 30W | 3150 | 4000K | 240×100 | 2,4 kg. |
| IDS-512-030-865 | 30W | 3210 | 6500K | 240×100 | 2,4 kg. |
