Myra-T II
- Açıklama
Description;
- Spotlight series with various size, power and lumen output options, works perfect for design when used in a combination. Different beam angles provide light effect from narrow to flood.
Technical Drawing
Features:
| Mechanical |
| Body: | Aluminium |
| Finish: | Electrostatic powder painted |
| Installation: | Ceiling recessed mounted |
| Diffuser: | Transparent safety glass |
| Optics: | Aluminium reflector |
| Louvre: | Dark or gold louvre options |
| Electrical |
| Driver: | LED driver with external connection |
| Light source: | COB LED |
| Frequency: | 220-240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Pf>0.90 | |
| Operating Temperature: | -20 / +50 |
| Options: |
| RAL selection |
| CRI>90 |
| CRI>97 |
| DALI |
| 0-10V / 1-10V |
| Casambi |
| GST connector |
| Emergency kit / CBS connection |
| Optical: |
| Beam angle: 15-30-45 degree |
| UGR:< 19 |
| CRI>80 |
| McAdams Step<3 |
| Technical Chart |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Weight (kg.) | Cut-out (mm.) | Dimensions (ØxH) (mm) |
| ISS-455-208-827 | 2×8 | 2700K | 1440 | 0.9 kg. | 225×105 | 200×100 |
| ISS-455-208-830 | 2×8 | 3000K | 1630 | 0.9 kg. | 225×105 | 200×100 |
| ISS-455-208-840 | 2×8 | 4000K | 1740 | 0.9 kg. | 225×105 | 200×100 |
| ISS-455-208-865 | 2×8 | 6500K | 1820 | 0.9 kg. | 225×105 | 200×100 |
