Rock SE
- Açıklama
Description;
Circular highbay luminaire with high efficiency and durable structure – suits all industrial areas. Ideal solution for retrofit projects to replace metal halide highbays.
Features
| Mechanical |
| Body: | Aluminium |
| Finish: | Electrostatic powder painted |
| Installation: | Surface mounted, adjustable mechanism |
| Optics: | PMMA LED Lenses |
| Electrical |
| Light Source | DOB LED Module |
| Frequency: | 220-240V 50/60 Hz |
| Lifetime: | 35.000 hours |
| Operating Temperature: | -20 / +50 |
| Options: |
| RAL selection |
| CRI>90 |
| 35.000 hours lifetime |
| DALI |
| Emergency kit / CBS connection |
| Watt-lumen options |
| Suspension accessory |
| Sensor applications |
| Optical: |
| Light Output: Direct |
| Beam angle: symmetric |
| UGR:< 21 |
| CRI>70 |
| McAdams Step<3 |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (WxL) (mm) | Weight(kg.) |
| ESS-470-100-830 | 100W | 9800 | 3000K | 200×240 | 1,0 kg. |
| ESS-470-100-840 | 100W | 9900 | 4000K | 200×240 | 1,0 kg. |
| ESS-470-100-865 | 100W | 10000 | 6000K | 200×240 | 1,0 kg. |
| Technical Chart |
| Art. Nr. | Power (W) | Lumen output | Colour temp. | Dimensions (WxL) (mm) | Weight(kg.) |
| ESS-473-300-830 | 300W | 27500 | 3000K | 300×300 | 2,2 kg. |
| ESS-473-300-840 | 300W | 27700 | 4000K | 300×300 | 2,2 kg. |
| ESS-473-300-865 | 300W | 28000 | 6000K | 300×300 | 2,2kg. |
