Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | Aluminium reflector |
| Diffuser: | Transparent safety glass |
| Installation: | Ceiling recessed mounted |
Electrical
| Light Source: | COB LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50,000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Fixed |
| Beam Angle: | 60° degrees |
| UGR: | <21 |
| CRI: | >80 |
| McAdams Step: | <3 |
Options
| RAL Selection: | Available |
| CRI Option: | CRI > 90 |
| Dimming: | DALI |
| Control: | Casambi – Bluetooth control – 3H – CBS |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (Q×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| ISS-416-007 | 7W | 760* | 2700K–6500K | 85×58 | 75 | 0,25 kg |
| ISS-416-012 | 12W | 1350* | 2700K–6500K | 85×58 | 75 | 0,25 kg |
| ISS-417-015 | 15W | 1625* | 2700K–6500K | 105×65 | 95 | 0,30 kg |
| ISS-418-020 | 20W | 2250* | 2700K–6500K | 131×75 | 115 | 0,45 kg |
| ISS-419-027 | 27W | 3100* | 2700K–6500K | 150×80 | 135 | 0,55 kg |
| ISS-420-033 | 33W | 3540* | 2700K–6500K | 191×95 | 175 | 0,90 kg |
| ISS-421-038 | 38W | 4100* | 2700K–6500K | 215×105 | 200 | 1,20 kg |
