Flora
- Açıklama
Description;
Outdoor wall mounted luminaire with down or up&down light options. Combined with the surface mounted downlight family, makes a great product for outdoor lighting design.
Features
| Mechanical |
| Body: | Aluminium |
| Finish: | Electrostatic powder painted |
| Installation: | Wall surface mounted |
| Optics: | PMMA lens |
| Electrical |
| Driver: | LED driver inside the body |
| Light Source: | COB LED |
| Frequency: | 220-240V 50/60 Hz |
| Lifetime: | 50.000 hours Pf>0.90 |
| Operating Temperature: | -20 / +50 |
| Options: |
| RAL selection |
| Optical: |
| Beam angle: Single or up&down |
| CRI>80 |
| McAdams Step<3 |
| Technical Chart |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Weight (kg.) | Dimensions (WxLxH) (mm) |
| EUS-921-030-830 | 30 | 3000K | 3100 | 8,2 Kg. | 80(W) x 4000(L) x 150(H) |
| EUS-921-030-840 | 30 | 4000K | 3175 | 8,2 Kg. | 80(W) x 4000(L) x 150(H) |
| EUS-921-030-850 | 30 | 5000K | 3310 | 8,2 Kg. | 80(W) x 4000(L) x 150(H) |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Weight (kg.) | Dimensions (WxLxH) (mm) |
| EUS-921-040-830 | 40 | 3000K | 4230 | 8,9 Kg. | 80(W) x 5000(L) x 150(H) |
| EUS-921-040-840 | 40 | 4000K | 4400 | 8,9 Kg. | 80(W) x 5000(L) x 150(H) |
| EUS-921-040-850 | 40 | 5000K | 4550 | 8,9 Kg. | 80(W) x 5000(L) x 150(H) |
| Art. Nr. | Power (W) | Colour temp. | Lumen output | Weight (kg.) | Dimensions (WxLxH) (mm) |
| EUS-921-060-830 | 60 | 3000K | 6200 | 9,9 Kg. | 80(W) x 6000(L) x 150(H) |
| EUS-921-060-840 | 60 | 4000K | 6450 | 9,9 Kg. | 80(W) x 6000(L) x 150(H) |
| EUS-921-060-850 | 60 | 5000K | 6600 | 9,9 Kg. | 80(W) x 6000(L) x 150(H) |
