Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | PC Lenses |
| Installation: | Wall surface mounted |
Electrical
| Light Source: | Mid Power LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Up&Down or Single Direction |
| CRI: | >80 |
| McAdams Step: | <3 |
Options
| RAL selection: | Available |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (Ø×H) mm | Light Direction | Weight (kg) |
|---|---|---|---|---|---|---|
| EGS-418-006 | 6W | 600* | 3000K-6500K | 70×160 | Single Sided | 1,50 kg. |
| EGS-419-012 | 2x6W | 1200* | 3000K-6500K | 70×240 | Up&Down | 2,00 kg. |
