Technical Drawing
Mechanical
| Body: | Metal sheet |
| Finish: | Electrostatic powder paint |
| Cover: | Tempered glass |
| Optics: | Opal diffuser |
| Installation: | Surface mounted |
Electrical
| Driver: | LED driver inside body |
| Light Source: | SMD LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Direct |
| Beam Angle: | 120° degrees |
| UGR: | <21 |
| CRI: | >80 |
| McAdams Step: | <3 |
Options
| RAL Selection: | Available |
| Micro-prismatic diffuser | UGR<19 |
| CRI Option: | CRI > 90 |
| Control: | DALI – Casambi – Bluetooth control – 3H – Tunable white |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (W×L×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| ITS-915-015 | 15W | 1650* | 2700K-6500K | 305x305x60 | N/A | 3,50 kg. |
| ITS-916-023 | 23W | 2450* | 2700K-6500K | 305x605x60 | N/A | 4,50 kg. |
| ITS-917-040 | 40W | 4300* | 2700K-6500K | 305x1205x60 | N/A | 7,50 kg. |
| ITS-918-040 | 40W | 4300* | 2700K-6500K | 605x605x60 | N/A | 7,00 kg. |
