Technical Drawing
Mechanical
| Body: | Aluminium |
| Finish: | Electrostatic powder paint |
| Optics: | Aluminium reflector |
| Diffuser: | Transparent safety glass |
| Installation: | Ceiling surface mounted |
Electrical
| Driver: | LED driver inside the body |
| Light Source: | COB LED |
| Frequency: | 220–240V 50/60 Hz |
| Lifetime: | 50.000 hours |
| Power Factor: | PF > 0.90 |
| Operating Temperature: | -20°C / +50°C |
Optical
| Light Effect: | Fixed |
| Beam Angle: | 60 degrees |
| UGR: | <21 |
| CRI: | >80 |
| McAdams Step: | <3 |
Options
| RAL Selection: | Available |
| CRI Option: | CRI > 90 |
| Control: | Casambi – Bluetooth control – 3H |
| DALI: | DALI-1-10V-Phase dimming |
| Suspension: | Suspension kit |
Technical Chart
| Art. No. | Power (W) | Lumen | Colour Temp (K) | Dimensions (Q×H) mm | Cut-out (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| ISS-475-010 | 10W | 1200* | 2700K–6500K | 75×100 | N/A | 0,3 kg |
| ISS-476-015 | 15W | 1800* | 2700K–6500K | 95×100 | N/A | 0,4 kg |
| ISS-477-020 | 20W | 2400* | 2700K–6500K | 115×152 | N/A | 0,7 kg |
| ISS-477-030 | 30W | 3600* | 2700K–6500K | 115×152 | N/A | 0,7 kg |
| ISS-478-040 | 40W | 4800* | 2700K–6500K | 140×162 | N/A | 1,0 kg |
